GM HEI Distributor Coil

(No reviews yet) Write a Review


This coil is a direct replacement of the stock coil and offers increased spark energy when used with the MSD-83647 HEI Module.

The coil features special low inductance, high temperature windings which charge faster to give you increased spark energy at higher rpm. The premium epoxy filled construction is designed to withstand harsh race applications as well as the wear and tear that daily usage dishes out, and still deliver more spark energy to the spark plugs.

• Direct performance replacement for GM HEI coil-in-cap distributors
• 70:1 turns ratio and lower primary resistance produce high voltage output
• Full power sparks to 9,000 RPM when used with MSD-83647 HEI Module
• Recommended for use with MSD-83647 HEI Module
• GCARB E.O. Approved

• Inductance: 3.5 mH
• Maximum voltage: 42,000 Volts
• Peak current: 200 mA
• Primary resistance: .31 OHMs
• Secondary resistance: 9.2K OHMs
• Spark duration: 200 uS
• Turns ratio: 70:1

Click here to download the MSD-8225 GM HEI Distributor Coil instructions.
